MHJ-K series of hand-held laser welding machine is a new generation of laser welding products, the laser selected is Rayco laser high-quality light source, the whole machine adopts integrated design, beautiful appearance and stable performance, easy to install and simple operation, high safety. It has the advantages of fast welding speed, high efficiency, good welding effect, less welding consumables, long life and environmental protection, and can be widely used in kitchen utensils, door and window guardrails, stair elevators, stainless steel furniture, metal sheet metal, billboards, craft gifts, automobile repair, automobile manufacturing, track communication and aerospace and other industries welding.
MHJ-K series of hand-held laser welding machine is a new generation of laser welding products, the laser selected is Rayco laser high-quality light source, the whole machine adopts
integrated design, beautiful appearance and stable performance, easy to install and simple operation, high safety. It has the advantages of fast welding speed, high efficiency, good
welding effect, less welding consumables, long life and environmental protection, and can be widely used in kitchen utensils, door and window guardrails, stair elevators, stainless steel
furniture, metal sheet metal, billboards, craft gifts, automobile repair, automobile manufacturing, track communication and aerospace and other industries welding.
MHJ-K series of hand-held laser welding machine standard wire distribution machine, reduce the requirements of parts on the gap, so that the welding quality is further improved.
It can also be used with the cooperative robot to fix the welding gun on the cooperative robot, reduce the labor intensity of the operator and improve the welding quality of the weld.
Product series | MHJ-K Series (Rayco Laser) |
Model number | MHJ-3000K |
Laser type | RFL-QCW 3000 |
Output power | 3000W |
Laser wavelength | 1080±5 nm |
Working mode | Continuous/modulation |
Power regulation range | 10 ~ 100% |
Fiber core diameter | 50 (25,100,200 optional) |
Aiming and fixing | Red light |
Fiber length | 10 m |
Welding speed | 0 ~ 120 mm/s |
Applicable thickness | < 3.5mm (depending on material) |
Wire feeder | Standard wire feed speed 38~600mm/min |
Feed diameter | 0.8/1.0/1.2/1.6/2.0mm |
Cooling mode | water-cooling |
Working environment | 10~40°C, humidity 10~85%, no condensation |
Rated power | 8KW |
Operating voltage | 380V、50/60Hz |
External dimension | 1060X505X1120 mm |
Machine weight | Approx. 250kg |
